L250W-UAE OEM Thermal Power/Energy Laser Sensor

Updated:2025-03-13

Brand：Ophir
Model：L250W-UAE
Description: The L250W-UAE is a water cooled OEM thermal power/energy laser sensor with a 50mm aperture. It can measure from 300mW to 250W. It can measure energy from 120mJ to 200J. It has the spectrally flat broa
Data download

Feedback
WeChat

QQ

Online Service

Product Details

L250W-UAE OEM Thermal Power/Energy Laser Sensor Description：

The L250W-UAE is a water cooled OEM thermal power/energy laser sensor with a 50mm aperture. It can measure from 300mW to 250W. It can measure energy from 120mJ to 200J. It has the spectrally flat broadband coating covering the spectral range from 0.19 to 20μm. It has Ethernet output.

L250W-UAE OEM Thermal Power/Energy Laser Sensor Drawing：

L250W-UAE Drawing

L250W-UAE OEM Thermal Power/Energy Laser Sensor Specifications：

Aperture	?50mm
Spectral Range	0.19-20μm
Power Range	0.3W-250W
Energy Range	120mJ-200J
Dimensions	80 L x 80 W x 58 D (mm)
Max Average Power Density	10kW/cm2 at 250W
Response Time	2.5 s
Max Energy Density(for <100ns)	0.3J/cm2
Max Energy Density(for 2ms)	10J/cm2
Max Average Power	250W water cooled free standing
Communication	Ethernet
